Introduction
After a week of daily use, the UGREEN US3000 UPS has already proven why it exists. Power protection isn’t glamorous, but even a short outage can corrupt drives or interrupt critical writes on a NAS.
UGREEN designed the US3000 to prevent that exact risk — not by adding complexity, but by integrating power management directly into UGOS Pro, the same operating system used in the NASync series. (If you want to see how it performs in practice, read my UGREEN NASync DXP2800 two-month review for a deeper look at daily reliability and real-world performance.)
Unlike most universal UPS units that rely on dated software and manual setup, this compact model is purpose-built for NASync devices. It feels more like a built-in safeguard than an accessory — quietly doing its job in the background.
Design and Build Quality
The US3000 is constructed from solid aluminium alloy, finished in the same matte silver-grey as the DXP-series NAS units. It’s small (120 × 80 × 30 mm, 440 g) yet dense, with precise machining and no flex.
Inside, it houses a 12 000 mAh (43.2 Wh) battery pack made from four SunPower INR18650-3000 cells wired in series. Dedicated circuitry manages charging, discharge rate, and temperature control, while the metal enclosure doubles as a passive heatsink.
The internal layout is clean and practical: foam-cushioned cells, Mylar-insulated wiring, and reinforced connectors. The supplied DC5525 and USB-C cables are short and tidy — ideal for rack or shelf setups. It’s clear UGREEN designed this as a true companion for its NAS line rather than a generic UPS.
Setup and Integration with NASync
Setup takes under five minutes. Connect the US3000 between your NAS and its power supply using the DC5525 lead, then attach the USB-C cable.
Once powered, UGOS Pro detects the UPS automatically under Control Panel → Hardware & Power → UPS. From there you can view charge status, voltage, and shutdown options — all without installing drivers or third-party software.
That seamless integration is what separates it from typical UPS units. The US3000 appears in UGOS Pro as a managed device, enabling automatic shutdown and recovery when power returns.
If you’re just starting out with your NASync, my beginner setup guide for the UGREEN DXP2800 covers this interface step by step.
Performance and Everyday Use
The US3000 focuses on one thing: controlled shutdowns. It’s not a long-duration backup — it’s protection done right.
UGOS Pro offers two response modes:
1. Standby Mode
• NAS continues running on battery during an outage.
• If mains returns quickly, it resumes seamlessly.
• If power doesn’t return, the NAS shuts down gracefully before the battery is depleted.
2. Auto Shutdown
• NAS immediately begins its shutdown sequence.
• Services stop cleanly and drives park safely.
• Once power is restored, it restarts automatically.
I keep mine set to Auto Shutdown — it’s the safest option for unattended use. In testing, both modes worked perfectly. The DXP2800 switched instantly to UPS power and completed its shutdown sequence cleanly, with zero voltage fluctuation.
Recharge takes about two hours, and because it uses DC-to-DC conversion instead of AC inversion, it runs completely silent and highly efficient.
If you’d like to see how the DXP2800 performs under typical workloads, the two-month NASync review includes real-world tests on transfer speeds, app stability, and power use.
Compatibility and Runtime Estimates
Runtime figures from NASCompares, ChargerLab, and UGREEN show the UPS is tuned for short, controlled operation.
| NAS Model | CPU | Max Draw | Est. Runtime |
|---|---|---|---|
| DXP2800 | Intel N100 | ≈ 35 W | ≈ 10 min |
| DXP4800 | Intel N95 | ≈ 45 W | ≈ 8–9 min |
| DXP4800 Plus | Intel Core i3-N305 | ≈ 55 W | ≈ 7 min |
| DXP8800 Plus | Intel Core i5-1235U | ≈ 70 W | ≈ 6 min |
| DH2600 / DX4600 | Various | < 50 W | ≈ 8–9 min |
Rated for 120 W DC output (12 V / 10 A, 19 V / 7.9 A, 20 V / 7 A), it easily handles every NASync model. No configuration is needed — UGOS Pro manages detection and shutdown automatically.
For context on how drive selection affects power usage, see Choosing the Best Drives for Your NAS – HDD vs SSD Recommendations.
Inside the US3000 (Teardown Insights)
ChargerLab’s full teardown of the UGREEN 120 W DC UPS shows just how well built this unit is.
It uses a Chipsea CBM8580KV6NT for battery management and SMBus communication, a Texas Instruments TPS55289 for buck-boost power regulation, and a GigaDevice GD32F303RCT6 microcontroller (Cortex-M4 @ 120 MHz) for logic and protection.
Each of the four battery cells is individually insulated and cushioned, while the PCB is shielded with Mylar and protected by dual fuses and thermistors. Wiring is reinforced, neatly routed, and the aluminium chassis itself acts as a heatsink.
It’s a compact, efficient design that would look right at home in professional-grade hardware.
Highlights
• Native integration – Full hardware-software link through UGOS Pro; zero configuration.
• Smart behaviour – Automatic standby and shutdown for controlled response.
• Premium build – Machined aluminium shell, insulated internals, efficient cooling.
• Power efficiency – DC-to-DC conversion for silent, stable operation.
• Effortless ownership – Quick recharge, no maintenance, seamless protection.
If you’re exploring ways to make your NAS more versatile, try Top 10 Docker Containers to Supercharge Your NAS — it’s packed with apps that complement a NASync setup perfectly.
Limitations
• Runtime – ≈ 43 Wh battery provides 6–10 minutes of backup; enough for graceful shutdowns, not long-term use.
• Device scope – Exclusive to UGREEN NASync systems.
• Availability – Still limited in retail channels but expected to expand soon.
For users wanting both on-site and off-site protection, pair this with Automated NAS Backup to Azure via Rclone Guide to create a full-stack backup strategy.
Final Verdict
After a week of use, the UGREEN US3000 UPS has become one of those accessories you forget about — until it saves your data. It’s compact, silent, efficient, and integrated so tightly with UGOS Pro that it feels like part of the NAS itself.
It won’t keep your system running forever, but it ensures it never shuts down the wrong way — and for NAS owners, that’s what really matters.
If you’re building or upgrading a NASync setup, the two-month UGREEN DXP2800 review offers detailed insights into everyday use and performance, while Best Home Security Cameras for Your NAS (Cloud vs PoE) covers surveillance options that pair perfectly with this UPS.
